Hager 2945 Universal Surface-Mounted Electric Strike for Rim Exit Devices

$486.75
This item ships FREE! Usually Ships:  3-5 Business Days
  • For use with rim exit devices
  • Accepts up to 3/4" throw pullman latch bolt
  • 12/24V AC/DC

Available Options:

Clear

Product Overview

Hager 2945 Universal Electric Strike - For Rim Exit Devices (up to 3/4" Pullman Latch), 12/24V AC/DC, ANSI/BHMA Grade 1, UL Listed 3-Hour Fire-Rated


The 2945 Series rim strike is Grade 1 classified and compatible with most 3/4" pullman latches. The 1,500 lbs. of static strength ensures security while its 1 million cycle testing offers durability. The 15 lbs. preload is unique to Hager and prevents the strike from failing to release due to air (stack) pressure, misalignment, and inexact installation.
  • Surface mounts to metal or wood door frame
  • Accepts up to 3/4" Pullman latchbolt
  • 12/24V AC/DC
  • Fail Safe/Fail Secure, Field Selectable
  • 15 lbs. preload
  • 1,500 lbs. of holding force
  • Metal mounting template
  • Latchbolt monitor switch
  • 9-1/8" L x  1-7/8" W x 3/4" D
  • ANSI A156.31 Grade-1
  • UL10C 3-Hour Fire Rating
  • Burglary UL 1034
  • Access Control UL294
Brand

Hager
Finishes

BLK Black, US32D (630) Satin Stainless Steel
Usage

Heavy Duty
Fire Rating

UL 10C (3-Hour)
Lock Type Compatibility

Rim Exit Device
Warranty

5 Year
