Trudoor

Trudoor TDE-KIL Exit Device Keyed Lever Trim – Entry/Classroom Function

$86.84
Usually Ships:  Same Day
  • For use with Trudoor TDE-1000/2000R Series rim exit devices
  • ANSI function 08: key locks/unlocks lever
  • Installs in a standard 2-1/8″ 161 door prep

Available Options:

Clear

Product Overview

Trudoor TDE-KIL Key-in-Lever Trim for TDE Exit Devices, Entrance/Classroom Function

For use with Trudoor TDE-1000R and TDE-2000R Series Rim Exit Devices

  • ANSI Function 08 – Entrance, key locks or unlocks lever – Operates as classroom function
  • Meets ANSI A156.3 Grade 1 standards
  • Steel, zinc dichromated chassis with secure thru-bolted design
  • ADA compliant lever design
  • Installs in 2-1/8″ 161 door prep
  • Cross-shaped stainless steel actuator
  • Non-handed, completely reversible
  • 6-Pin brass cylinder, Schlage C keyway, keyed different
  • Includes 2 cut keys
ANSI Grade

ANSI Grade 1
Brand

Trudoor
Cylinder & Keys

6-pin conventional keyed different with 2 keys
Door Applications

1-3/4" Metal and Wood Doors
Finish

BlackSatin Chrome
Finishes

622 Matte BlackUS26D (626) Satin Chrome
Function

Entry / Classroom
Handing

Non Handed – Completely Reversible
Keyway

Schlage C Keyway
Usage

Medium Duty
